ORBEA GAIN D30 105 DISC E-ROAD BIKE 2021

With a lightweight and nimble aluminium frame and clean, unobtrusive cable management, you'd be forgiven for thinking the Orbea Gain D30 105 Disc E-Road Bike doesn't have a motor or battery at all. Ride it up a steep hill, hit the power button and you'll instantly feel the helping addition of 250 watts through the rear hub motor, powered by a sleek 248wh battery concealed in the downtube.

The power is there when you need it and unobtrusive when you don't, so you're still very much in control of this bike and not the other way around. There are some really neat touches too, with the integrated lights sitting in the seatpost and on the out-front interface, so you'll have light whenever you need that too.

The Shimano 105 groupset hits the sweet spot between performance and affordability, with an 11-speed setup that shifts crisply and effortlessly, while the powerful hydraulic disc brakes make light work of your braking. Rolling on a set of 30mm Hutchinson Fusion 5 tyres, you've got the comfort you need for long days in the saddle with a smile on your face.

HIGHLIGHTS

The Mahle Ebikemotion X35 Plus motor is designed to improve your rides, not dominate them

Motor is located on the wheel axle, not the bottom bracket, so you’ll enjoy pedalling without resistance when the power assist is off

ICR Plus internal cable routing keeps the cockpit clean looking

Integrated lights

Mahle Ebikemotion 248Wh battery neatly housed in the downtube

Mahle Ebikemotion iWoc ONE interface displays battery and assist levels as you ride

Hydroformed Aluminium frame is lightweight and robust

Endurance geometry is perfect for riding all day long

Shimano 105 11-speed groupset

Hutchinson Fusion 5 Performance TLR tyres are 30mm wide for plush comfort on the road

BATTERY SPECIFICATION

Maximum Assist: 250w up to 25km/hr

Motor Weight: 3.5kg

Range: Up to 47 miles / 75km depending on usage and riding conditions

Battery Power: 250Wh

SPECIFICATION

Frame   Orbea Gain Hydro 6061 Hydroform Aluminium 2021, ICR cable routing, Forged BB, safety screw, 135x9 QR, Flat Mount disc mount, 700x40 maximum tyre, 1" 1/2 semi-integrated headset, 41 x 86.5 Pressfit bottom bracket

Fork       Orbea Gain Hydrocarbon fork, full carbon, 1-1/8" - 1.5" tapered head tube compatible, 700x40 maximum tyre, flat mount disc mount, Thru-axle 12x100mm

Headset               Orbea Acros Alloy 1-1/2" Internal Cable Routing

Stem     Orbea OC1 31.8mm interface -6º

Handlebar           Orbea OC2 Road, reach 80mm, drop 125mm

Front Brake        Shimano 105 R7020 hydraulic disc

Rear Brake          Shimano 105 R7020 hydraulic disc

Brake Levers      Shimano 105 R7020 hydraulic disc

Rear Derailleur  Shimano 105 R7000 GS 11-speed

Front Derailleur                Shimano 105 R7000

Shift Levers        Shimano 105 R7020

Chain     KMC X11

Cassette              Shimano 105 R7000 11-32t 11-speed

Crankset              Shimano 105 R7000 34x50t

Front Wheel       Blackjack Ready GR clincher

Rear Wheel        Blackjack Ready GR clincher

Front Tyre           Hutchinson Fusion 5 Performance TLR 700x30c clincher

Rear Tyre             Hutchinson Fusion 5 Performance TLR 700x30c clincher

Saddle                  Selle Royal Asphalt GR

Seatpost              Orbea OC 27.2 Offset 0, for integrated light

Pedals                   Available to be purchased separately

Accessories        60 Lumen COB LED front light on display holder, 11-lumen Lezyne STVZO seatpost mounting rear light

Motor                   Mahle Ebikemotion X35 Plus 25kmh (250 watts, 40Nm maximum torque)

Remote                Mahle Ebikemotion iWoc ONE

Battery                 Mahle Ebikemotion 36V/6.9A 248Wh ANT+

Charger                Mahle Ebikemotion X35
