2023 Canyon Ultimate CF SL 8 Aero Road Bike

Description

2023 CANYON ULTIMATE CF SL 8 AERO ROAD BIKE

The perfect balance

When developing the Ultimate, our goal was to strike the perfect balance between lightness, stiffness, comfort, robustness, and aerodynamics. The result? The most balanced, best-value road bike on the scene.

Aerodynamically optimised

On the road, from just 14 kph, aerodynamic drag is the largest force holding you back. So we optimised the frame forms for minimum drag, through an exhaustive process of wind tunnel testing in collaboration with aero experts Swiss Side. We also integrated the headtube/fork area as much as possible for extra aero gains.

High-grade carbon layup

The CF SL combines the cutting-edge innovations of the SLX and CFR platforms with a carbon layup that strikes the ideal balance between durability and value. By using specially selected fibres, the carbon layup sets the benchmark in terms of toughness.

A new integrated aero seatpost

The Ultimate looks even cleaner and sleeker with this clamp design. The clamp is hidden away in the seat tube, so there’s no extra drag. We combine it with a D-shaped seatpost to reduce air resistance in the seat tube area to an absolute minimum.

SPECIFICATION :

Frame	Canyon Ultimate CF SL Latest 5th-generation Ultimate frame. Classic road race design, engineered for the perfect balance of comfort, toughness, stiffness, lightness, and aerodynamics. Axle dimension: 12x142 mm Material: Carbon (CF)
Fork	Canyon FK0104 CF Axle dimension: 12x100 mm Material: Carbon (CF)
Rear Derailleur	Shimano Ultegra Di2 R8150, 12-speed
Front Derailleur	Shimano Ultegra Di2 R8150, 12-speed
Cassette	Shimano Ultegra R8100,12-speed, 11-30T Number of sprockets:12
Crank	Shimano Ultegra R8100 4iiii Precision Powermeter Number of chainrings: 2
Bottom bracket	Token Ninja Lite BB4124 Bottom bracket standard: PF 86,5
Chain	Shimano CN-M8100 12s
Shift-/ Brake Lever	Shimano Ultegra Di2 R8170 12s
Shift-/ Brake Lever	Shimano Ultegra Di2 R8170 12s Number of pistons: 2
Brake Rotor	Shimano RT-CL800 Size: 140 mm
Brake Rotor	Shimano RT-CL800 Size: 160 mm
Wheel	DT Swiss ARC 1600 Axle dimension: 12x100 mm Rotor mount: Center Lock Rim height: 50 mm Wheelsize: 28"
Wheel	DT Swiss ARC 1600 Dicut Axle dimension: 12x142 mm Rotor mount: Center Lock Rim height: 62 mm Wheelsize: 28"
Tyre	Schwalbe One TLE, 25mm Width: 25mm
Tyre	Schwalbe One TLE, 28mm Width: 28mm
Thru Axle	Canyon Thru Axle 12x100x1,75 Axle dimension: 12x100 mm
Thru Axle	Canyon Thru Axle 12x142x1,75 Axle dimension: 12x142 mm
Cockpit	Canyon CP0018 Aerocockpit Aero design, reinforced carbon walls for added stiffness and improved durability. Easy width adjustment: +/-20 mm Cut-free height adjustment: 15 mm Material: Carbon (CF)
Handlebar Tape	Canyon Ergospeed Gel Color: black
Saddle	Selle Italia SLR Boost Superflow S manganese Gender: Unisex
Seatpost	Canyon SP0055 Custom carbon seatpost with aerodynamic D-shape profile. Setback: 10 mm Weight: 110 g
Light	Reflector Set
Pedals	None included
Manuals and Accessories	Canyon starter box
Manuals and Accessories	Canyon Smallbox
Manuals and Accessories	Quickstart Guide Ultimate CF

2023 Canyon Ultimate CF SL 8 Aero Road Bike

Product Code: CY654389
